    Konica Minolta

    CM-25d

    CM-25d Portable Spectrophotometer

    • CM-25d Portable Spectrophotometer

      The Konica Minolta CM-25d is a next-generation portable sphere spectrophotometer designed for measuring the color of flat or large samples in narrow spaces. It offers superior accuracy and inter-instrument agreement, making it ideal for color communication throughout the supply chain. The instrument is ergonomically designed for easy operation by right or left-handed users and is equipped with an illuminated viewfinder for accurate positioning.

      The Konica Minolta CM-25d Portable Sphere Spectrophotometer is an ideal instrument for color measurement in narrow spaces. With its precision, accuracy, ergonomic design, and additional features, it sets a new standard for easy and fast data handling, improving workflow, eliminating waste/rework, and offering customers general cost savings on color-related processes.

      Accuracy
      Precision and Accuracy

      The CM-25d offers superior accuracy and inter-instrument agreement with an IIA of 0.2 DE* (average of 12 BCRA tiles). This precision enables superior color communication throughout the supply chain from supplier to final assembly.



      The CM-25d Portable Spectrophotometer comes with SpectraMagic NX colour measurement software package that can be used to interface with Konica Minolta instruments and provide extended reporting and analysis of colour and colour difference.

      Measurement Area and Design

      The instrument has an Ø8mm measurement area and is designed to minimize subject damage, providing repeatable results. The instrument surfaces that come in contact with the measurement subject are comfortable for both right-handed and left-handed users.

      TouchScreen
      Aperture Size
      Ergonomic Design and Features

      The CM-25d is lightweight and ergonomically designed for field applications. It features an optional Bluetooth™ and high-resolution TFT color display for easy data handling. The instrument offers filtering of stored data based on additional information (tagging) and image-based workflows for easy and simple usage by operators with limited instrument experience.

      Job Function

      The new Job function allows for graphical representation/instructions for routine color measurements to be made within specific processes. This feature, combined with a reduced measurement time, allows users of all levels to maintain high levels of productivity, accuracy, and consistency.

      WaveLength
      CT1
      CM-CT1 Configuration Tool

      The CM-25d comes with the CM-CT1 Configuration Tool software, which allows users to create and write instrument settings and compile them into a file to share within its supply chain to ensure consistent instrument settings.



      The New Color Data Software SpectraMagic NX2 - Pro version / Lite version



      SpectraMagic™ NX2 is an improved software solution for digital color data, developed to allow users a streamlined system for operating Konica Minolta color measuring instruments, capturing, comparing and communicating color data within the business and between supply chain partners. SpectraMagic™ NX2 offers users a far smoother experience than its predecessor SpectraMagic™ NX.







      Optimize Color Control with SpectraMagic NX2

      SpectraMagic NX2 by Konica Minolta is a cutting-edge software designed to meet the demanding needs of color quality control across various industrial sectors. Whether you are in the automotive, paint, plastics, cosmetics, or food industries, this software offers a complete and intuitive solution for precise color analysis.





      Installation procedure

      1. Save the download file (for example, smnx2_verxxx_all.zip, where xxx is the software version number) to a folder on your computer.
      2. Extract the files in the downloaded zip file to a folder on your computer.
      3. Open the Installation Guide (smnx2_install_multi.pdf) in the files extracted in step 2.
      4. Follow the procedure described in the Installation Guide for installing SpectraMagic NX2.



      Minimum Computing Requirements*3

      OS: Windows® 10 Pro 64 bit Version 1903 or higher/
      Windows® 11 Pro
      CPU: Intel® Core i5 2.7 GHz or higher processor (recommended)
      Memory: 2 GB or more (4 GB or more recommended)
      Storage: 10 GB or more
      USB port: Required for dongle version
      Connection to external network: Required for activation



      Main features

      Observer 2°, 10°
      Color system
      color space
      Pro, Lite L*a*b*, L*C*h, Lab99, LCh99, Lab99o, LCh99o, Hunter Lab, and their color differences; Munsell (C, D65)
      Pro Only XYZ, Yxy, u'v', u*v*, and their color differences
      Index Pro, Lite MI; GU and difference (CM-25cG, CM-26dG, CM-36dG/CM-36dGV); Opacity (ISO 2471, TAPPI T425 89% white plate)*2
      CM-5/CR-5 only: Gardner, Iodine Color Number, Hazen/APHA, European Pharmacopeia, US Parmacopeia
      Pro Only WI (CIE1982, ASTM E313-73, Hunter, ASTM E313-98, BERGER, TAUBE, STENSBY, Ganz); YI (ASTM D1925-70, ASTM E313-73, ASTM E313-98, DIN 6167); B (ASTM E313-73); Tint (CIE 1982, ASTM E313-98, Ganz); Standard Depth (ISO 105.A06); Brightness (TAPPI T452, ISO 2470); Density (Status A, Status T); Dominant Wavelength; Excitation Purity; 555; RxRyRz; Grey Scale/Grey Scale Rating (ISO 105.A05); K/S Strength (Apparent, (ΔE*ab, ΔL*, ΔC*, ΔH*, Δa*, Δb*, Maximum absorption, Total wavelength, User wavelength); Strength; Pseudo strength; Staining degree/degree grade (ISO 105.A04E); NC#; NC#Grade; Ns; Ns Grade; Signal color index; 8° gloss/8° gloss difference (for simultaneous SCI/SCE measurements only); FF/FF difference (CM-M6); User equation; Haze (ASTM D1003-97)*2; Blackness(My) (ISO18314-3/DIN55979), Jetness(Mc) (ISO18314-3), and Undertone(dM) (ISO18314-3)
      Color
      Difference
      Formula
      Pro, Lite ΔE*ab (CIE1976); ΔE00 (CIE DE2000) and each component of lightness; saturation and hue; ΔE99(DIN99), ΔE(Hunter); ΔE*94 (CIE 1994) and each component of lightness; saturation and hue; CMC and each component of lightness; saturation and hue; ΔE99o and each component of lightness; saturation and hue
      Pro Only ΔE*94 (Special) and each component of lightness; saturation and hue; ΔEc(degree)(DIN 6175); ΔEp(degree)(DIN 6175; FMC-2; NBS 100; NBS 200; Audi2000
      Illuminant Pro, Lite A, C, D50, D65, F2, F11
      Pro Only D55, D75, F6, F7, F8, F10, F12, U50, ID50, ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LED-V1, LED-V2, User illuminant (100 maximum)
      Graphic
      and
      canvas
      objects
      Pro, Lite Spectral reflectance (transmittance) and its difference; L*a*b* absolute color distribution; Hunter Lab absolute color distribution; ΔL*a*b* color difference distribution; Hunter ΔLab; xy chromaticity diagram; Trend graph; Histogram; Multichannel graph; 2D user-specified axis graph Text labels, Numerical labels, Images, Data lists, Statistics, Pseudo-color patches
      Pro Only K/S and its difference; Absorbance and its difference
      Features Pro, Lite Viewfinder (CM-36d series); Manual averaging measurement; Trigger measurement (excluding CM3700A, CM-3600A and CM-3610A) Categorize by tags; Attaching images/comments; Evaluation results·pass/fail judgment; Import/export; Stored data reading/target data writing (excluding CM-3700A, CM-3600A, CM-3610A and CM-36d series) Shortcut key settings; Display template creation / output / application; Report printing; Printing to serial printer; Sound (on measurement, pass judgment, fail judgment)
      Pro Only User calibration, UV adjustment Interval measurement User management/operation restrictions Data search under specified conditions; User illuminant source registration (manual input, from file, from CL-500); Automatic selection of standards; Auto tolerance; Classification by user defined information QC template creation/editing/output; Macro function; External software startup; Job settings (CM-26d/ CM-25d/CM-26dG, CM-25cG)
      Number of files and data Number of files that can be opened simultaneously: 10 Number of data that can be stored in a file: 10,000 (total of target data and measurement data)
      Supported file formats NX2 (.mesx2, .mtpx2), NX (.mtp, .mes, .mea; reading only); Other (.csv (output only), .cxf); SpectraMagic DX files (.mesx) need to be converted to .mes with a conversion tool NX2 QC template *.qctp (PRO: create/edit/save, LITE: read only)
      Display languages Japanese, English, German, French, Spanish, Italian, Portuguese, Chinese (Simplified and Traditional), Turkish, Russian, Polish, Korean

      Compatible instruments

      CM-36dG/36dGV/36d, CM-3700A, CM-3600A, CM-3610A, CM-3630, CM-2600d/2500d, CM-2500c, CM-26dG/26d/25d, CM-25cG, CM-700d/600d, CM-512m3A, CM-5/CR-5, CR-400/410, DP-400, FD-7, FD-5
