- Techkon SpectroDens Basic
What is included?
- The measurement device
- A Charger
- Console with integrated white standard
- AC adapter with universal plugs
- Device case
- USB-cable
- CD with SpectroConnect software
- Manual with ISO 9000 certificate and a two year warranty
Techkon SpectroDens Basic
Basic SpectroDens Features
Automatic Density, Gray Balance Measurement
Spectrodens detect how much ink is concentrated in an area and inform ink density adjustment that will give the best color match. A unique report shows density variation across press along with adjustment for each section.
Densities CMYK, Spot Color Density
Both CMYK density and spot color density can be controlled to user preferences.
Dot Gain, Dot Area, Contrast
The device can determine solid ink density, percents dot area, gray balance and deltaE color datas which are critical for Pantone™ and important brand colors.
Ink Trapping
A unique feature for saving ink. It removes the corners of detail from a letter forms, then during the printing, the ink naturally spread to the removed corners.
Standard USB interface/ Wireless wifi communication(wifi optional)
Has optional Wireless communication of measured values to the PC running Techkon SpectroConnect software, using standard WLAN network protocol (WiFi).
Scan Single or Multiple Row Color Bars (Print Curve Density)
No attachments are needed when scanning color bars up to 8 inches in length. There are 4 integrated guided wheel at the bottom of the machine.
Printing Plate
Beside energy and focus of the laser, dot gain is the most important information which has to be checked in plate exposure. Special plate measuring instruments working with video analysis have been developed for this application
Slur and Doubling Value
With the measurement function Slur and Doubling printing deficiencies, caused by inexact, geometrical transfer of the image from the plate to the paper can by evaluated.
Expresso Mini (Density Trend)
Make sure that your solid ink densities are accurate and consistent by quickly and efficiently measuring and displaying individual solid ink densitiesin each ink zone throughout the color bar.
- Intuitive Display - Easy to read graphic and numeric display of average solid ink density measurements throughoutthe color bar.
- Quickly Identify Problem Areas - Displays individual solid ink densities throughout the color bar quickly identifying problem areas across the press sheet.
SpectroDens Model Comparison
VIDEO: Techkon SpectroDens

Watch Video
Variant | 1 |
---|---|
List price | $4,200.00 |
Product Actual Weight | 1.1 lbs |
Physical Size (H x D x W) | 7.3 x 2.0 x 2.4 inches |
Computer OS | Win XP (32 bit), Win XP (64 bit), Win Vista (32 bit), Win Vista (64 bit), Windows 7 (32 bit), Windows 7 (64 bit), Windows 8 (32 bit), Windows 8 (64 bit), Windows 10 (64 bit) |
Warranty | Limited Manufacturer Warranty |
ICC Version | No |
Automated | No |
Color System | Spectral, LAB, XYZ Color Model |
CTP Plates | No |
Density | Dot Gain, Dot Area, Trapping, Print Contrast, Grayness, Automatic Color Recognition, Pass/Fail Indicator, G7 Calibration, Polarization Filter |
Measurement Aperture Size | 3 mm round standard |
Measurement Time | 1 second per measurement, 0.8 seconds in scan mode |
Pantone Library Included | No |
Print Surface | No |
Uses | No |
Max CMYK Printer Profiling Patches | No |
CMYK Printer Profiling | No |
Monitor Profiling | No |
Max Multi-Color Printer Profiling Patches | No |
Profiling Choices | No |
Max RGB Printer Profiling Patches | No |
Supported Color Measurement Devices | No |
Supported Color Measurement Devices via ColorPort Software | No |
